Engine handoff video · 35 seconds

Export one PBR texture set for Unity and Unreal Engine

Watch a PBR stack move from generation to engine handoff, then download the Unity import script, Unreal Python helper, and the exact cross-engine export profile.

Reviewed by the PLAYTEX AI Editorial Team · Updated

PLAYTEX AI technical workflow · 35 seconds · English captions

Direct answer

What should you do?

Export a neutral source stack, then adapt the delivery package: Unity needs explicit texture importer roles and shader-specific smoothness handling; Unreal commonly uses DirectX-style tangent normals and packed occlusion, roughness, metallic channels. Keep the source maps as masters and make engine-specific files as derived outputs.

Video chapters

  1. 0:00 — Start from one reviewed source

    Treat the aligned material stack as the engine-neutral master.

  2. 0:05 — Choose the generation mode

    Resolve source decisions before target-specific conversion.

  3. 0:11 — Review every channel

    Catch missing or shifted maps before packing and normal conversion.

  4. 0:18 — Tune material behavior

    Approve the physical response before deriving engine files.

  5. 0:24 — Freeze the source manifest

    Record convention, color space, and channel roles.

  6. 0:28 — Create Unity and Unreal packages

    Derive importer settings, packed maps, helper code, and validation notes.

Step-by-step implementation

  1. Preflight the set. Confirm dimensions, bit depth, alpha use, normal convention, and missing channels before conversion.
  2. Choose the target profile. Select the Unity render pipeline and shader or the Unreal material layout before packing data.
  3. Generate derived files. Flip normal Y only when needed, invert roughness to smoothness where required, and pack channels for the selected shader.
  4. Run the editor helper. Apply importer settings, create the native material, then verify it under an engine light rig.

Key decisions

  • Do not overwrite engine-neutral master maps with target-specific packed files.
  • Confirm the normal Y convention instead of trusting a filename suffix.
  • Scalar data maps must bypass sRGB sampling in both engines.
  • Packing reduces texture fetches only when the target shader actually reads that channel layout.

Key frames and map details

PLAYTEX AI PBR Engine Converter with source map detection and target profile controls
The conversion profile makes normal convention, packing, and importer changes explicit.
Roughness source map before Unity or Unreal target conversion
Keep roughness as the neutral source even when a Unity shader expects smoothness.
Metallic source map before Unity or Unreal channel packing
Metalness stays linear and can be packed only after the target layout is chosen.

Cross-engine export profile excerpt

{
  "sourceNormal": "OpenGL-Y+",
  "unity": { "normalY": "project-dependent", "packed": "shader-dependent" },
  "unreal": { "normalY": "DirectX-Y-", "packed": "R=AO,G=roughness,B=metallic" },
  "dataMapsUseSRGB": false
}

How to know the result is correct

Compare the same neutral sphere in Unity and Unreal under equivalent white lighting. Check highlight width, normal direction, metal/dielectric boundaries, AO strength, and texture import flags—not just whether files loaded without errors.

Video transcript

  1. 0:00 The PBR map workflow begins with one source and one aligned material stack.

  2. 0:05 Choose image, procedural, or hybrid generation before engine conversion.

  3. 0:11 Review albedo, normal, roughness, metallic, AO, height, and emission together.

  4. 0:18 Tune material response and validate the surface under changing light.

  5. 0:24 Keep deterministic settings and the reviewed source stack as the master.

  6. 0:28 Export target-specific packages for Unity, Unreal, and the other supported renderers.
